TIE ROD END | JIKIU - ET24281R

Specification

Mounting Length (mm):

75

Thread (in/out)

M14x1.5 RHT

Thread (Cone out)

M14x1.50

Cone Size Ø(mm) :

16.5

Cone Pitch:

1:8

Overall Height (mm):

78

Full Lenght (mm):

94

Mounting Height (mm):

38.4

Location

Steering system

Position

Right

Parent Assembly

Brands

JIKIU

Part

SS24280

Type

SIDE ROD ASSY

Couple

Number

ET24281L

Crosses

Owner
Number
555 SANKEI
SE5281R
CTR
CE0259
CTR
CEIS-20
GM
94419408
GM
94459480
GM
97020953
ISUZU
8-94419-408-0
ISUZU
8-94419-408-1
ISUZU
8-94459-480-0
ISUZU
8-94459-480-1
Owner
Number
ISUZU
8-94459-480-2
ISUZU
8-97020-953-0
ISUZU
8-97020-953-1
ISUZU
8-97940-616-0
ISUZU
8-97956-902-A
LYNXauto
C4169R
OPEL
09 20 373
PROTEX
TE-967
TRW
ES-2953
