TIE ROD END | JIKIU - ET23641
Specification
Mounting Length (mm):
84.5
Thread (in/out)
M14x1.5 RHT
Cone Size Ø(mm) :
13.2
Cone Pitch:
1:6
Thread (Cone out)
M12x1.25
Overall Height (mm):
69.5
Full Lenght (mm):
105
Mounting Height (mm):
36
Location
Steering system
Position
Left/Right
Sub Assembly
Crosses
Owner
Number
555 SANKEI
SE-7641
CTR
CE0619
CTR
CES-17
FeBest
0721-SX4
LYNXauto
C4321LR
MARUTI
48810 M 65M00
MASUMA
ME-9960
SUZUKI
48810-65J00
Owner
Number
SUZUKI
48810-79J00
SUZUKI
48810-79J01
SUZUKI
48810-B79J0
SUZUKI
4881073R00
SUZUKI
4881073R00000
SUZUKI
4881079J01000
SUZUKI
48810M65M00-000
